| 轴承型号 | 尺寸（mm） | 重量(kg) | |||||||||||
| d | Be | D | B1 | n | m | Bi | K | H | G | h | ds | ||
| SA201 | 12 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.13 |
| SA201-8 | 12 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.13 |
| SA202 | 15 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.12 |
| SA202-10 | 15 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.12 |
| SA203 | 17 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.1 |
| SA203-11 | 17 | 12 | 40 | 19.1 | 6 | 13.1 | 28.6 | 28.6 | 13.5 | 5 | 3.6 | M6X1.0 | 0.1 |
| SA204-12 | 20 | 14 | 47 | 21.5 | 7.5 | 14.5 | 31 | 33.3 | 13.5 | 5 | 4 | M6X1. 0 | 0.16 |
| SA204 | 20 | 14 | 47 | 21.5 | 7.5 | 14.5 | 31 | 33.3 | 13.5 | 5 | 4 | M6X1. 0 | 0.16 |
| SA205-14 | 25 | 15 | 52 | 21.5 | 7.5 | 14 | 31 | 38.1 | 13.5 | 5 | 4.3 | M6X1. 0 | 0.19 |
| SA205 | 25 | 15 | 52 | 21.5 | 7.5 | 14 | 31 | 38.1 | 13.5 | 5 | 4.3 | M6X1. 0 | 0.19 |
| SA205-16 | 25 | 15 | 52 | 21.5 | 7.5 | 14 | 31 | 38.1 | 13.5 | 5 | 4.3 | M6X1. 0 | 0.19 |
| SA206-18 | 30 | 16 | 62 | 23.8 | 9 | 14.8 | 35.7 | 44.5 | 15.9 | 6 | 5 | M8X1. 0 | 0.3 |
| SA206 | 30 | 16 | 62 | 23.8 | 9 | 14.8 | 35.7 | 44.5 | 15.9 | 6 | 5 | M8X1. 0 | 0.3 |
| SA206-19 | 30 | 16 | 62 | 23.8 | 9 | 14.8 | 35.7 | 44.5 | 15.9 | 6 | 5 | M8X1. 0 | 0.3 |
| SA206-20 | 30 | 16 | 62 | 23.8 | 9 | 14.8 | 35.7 | 44.5 | 15.9 | 6 | 5 | M8X1. 0 | 0.3 |
| SA207-20 | 35 | 17 | 72 | 25.4 | 9.5 | 15.9 | 38.9 | 55.6 | 17.5 | 6.5 | 5.7 | M8X1.0 | 0.45 |
| SA207-22 | 35 | 17 | 72 | 25.4 | 9.5 | 15.9 | 38.9 | 55.6 | 17.5 | 6.5 | 5.7 | M8X1.0 | 0.45 |
| SA207 | 35 | 17 | 72 | 25.4 | 9.5 | 15.9 | 38.9 | 55.6 | 17.5 | 6.5 | 5.7 | M8X1.0 | 0.45 |
| SA207-23 | 35 | 17 | 72 | 25.4 | 9.5 | 15.9 | 38.9 | 55.6 | 17.5 | 6.5 | 5.7 | M8X1.0 | 0.45 |
| SA208-24 | 40 | 18 | 80 | 30. 2 | 11 | 19.2 | 43.7 | 60.3 | 18.3 | 6. 5 | 6.2 | M8X1. 0 | 0.6 |
| SA208-25 | 40 | 18 | 80 | 30. 2 | 11 | 19.2 | 43.7 | 60.3 | 18.3 | 6. 5 | 6.2 | M8X1. 0 | 0.6 |
| SA208 | 40 | 18 | 80 | 30. 2 | 11 | 19.2 | 43.7 | 60.3 | 18.3 | 6. 5 | 6.2 | M8X1. 0 | 0.6 |
| SA209-26 | 45 | 19 | 85 | 30.2 | 11 | 19.2 | 43.7 | 63.5 | 18.3 | 6.5 | 6.8 | M8X1.0 | 0.64 |
| SA209-27 | 45 | 19 | 85 | 30.2 | 11 | 19.2 | 43.7 | 63.5 | 18.3 | 6.5 | 6.8 | M8X1.0 | 0.64 |
| SA209 | 45 | 19 | 85 | 30.2 | 11 | 19.2 | 43.7 | 63.5 | 18.3 | 6.5 | 6.8 | M8X1.0 | 0.64 |
| SA209-28 | 45 | 19 | 85 | 30.2 | 11 | 19.2 | 43.7 | 63.5 | 18.3 | 6.5 | 6.8 | M8X1.0 | 0.64 |
| SA210-30 | 50 | 20 | 90 | 30.2 | 11 | 19.2 | 43.7 | 69.9 | 18.3 | 6.5 | 6.5 | M8X1. 0 | 0.71 |
| SA210-31 | 50 | 20 | 90 | 30.2 | 11 | 19.2 | 43.7 | 69.9 | 18.3 | 6.5 | 6.5 | M8X1. 0 | 0.71 |
| SA210 | 50 | 20 | 90 | 30.2 | 11 | 19.2 | 43.7 | 69.9 | 18.3 | 6.5 | 6.5 | M8X1. 0 | 0.71 |
